Product: ITM Air Compressor Stationary 10HP | 270L | 3 Phase
Specifications:
-
SKU: TM353-10270
-
Product Type: Connector
-
Material: Brass
Additional Details:
- ITM Air Compressor Stationary 10HP | 270L | 3Phase
- Material: FEATURES• Triple cast iron cylinder oil lubricated pump withaluminium head.• Powerful high efficiency induction motor.• Soft start valve for electric motor protection.• Thermal overload protection with manual reset.• Full brass non-return valve.• Certified safety valve.• Reliable Condor pressure switch.• Includes twin outlet one-touch “Nitto style” connectors.
- SPECIFICATIONS• Motor: 10HP - Three Phase 415V• Tank Capacity: 270 L• Max Pressure: 147 PSI (10 Bar)• Pump Displacement: 1269 L/min (44.8 CFM)• Free Air Delivery: 1143 L/min (40.4 CFM)• Pump RPM: 950• Package Dimensions: 161cm L x 62cm W x 131cm H• Compressor Dimensions: 155cm L x 54cm W x 112cm H
