Direct oil fired heaters – low pressure
Direct oil heaters are highly efficient devices that provide large volumes of instant heat where it is required. They are ideal for open or well-ventilated areas like factories, warehouses or construction sites. Master direct heaters are known for their efficiency, robustness, ease of use and operational safety.
Key features
-
High air flow
-
Two oil filters – oil tank filter and suction filter
-
Thermally protected motor
-
Electronic flame control with photocell
-
Stainless steel combustion chamber
Product specifications
| Specifications |
Units |
B 70 |
| Heating power |
kW
|
20
|
| Heating power |
Btu/h
|
68,300
|
| Heating power |
kcal/h
|
17,200
|
| Air flow |
m³/h
|
400
|
| Fuel autonomy |
h
|
10
|
| Thermostat control |
|
Analogue or digital
|
| Fuel consumption |
l/h
|
1.9
|
| Power supply |
V/Hz
|
220/240/50-60
|
| Electric power |
kW
|
0.18
|
| Rated current |
A
|
0.8
|
| Protection |
|
IP41
|
| Tank capacity |
l
|
19
|
| Product size (l x w x h) |
mm
|
745 x 300 x 405
|
| Box size (l x w x h) |
mm
|
810 x 350 x 450
|
| Net/gross weight |
kg
|
15/18
|
| Pallet |
pcs
|
15
|
| Dual voltage |
|
No
|
