Reverse Camera Universal Brake Light And Reversing Camera

Description

The CAM-29 is a universal rear brake light reversing camera, compatible with most vehicles that feature one rear door with a large window. This camera’s 1/3” CMOS, 600 TV line and 756 x 504 resolution allow full colour high res images. The CAM-29 also features Infra-Red LEDs allowing night vision for excellent image clarity in all lighting conditions The CAM-29 is also IP68 rated, meaning it is protected against all standard weather conditions and will continue to operate in temperatures ranging from -20 degrees C to +70 degrees C.

Product Specifications

• Image Sensor: 1/3” CMOS

• TV Lines: 600

• Resolution: 756 x 504

• Minimum Illumination: 0.1 Lux (0 Lux when IR on)

• TV System: NTSC

• Waterproof Rating: IP68

• Infra-Red LED’s: Yes

• Viewing Angle: 170 Degrees

• Enhanced Performance In Low Light: Yes

• Video Output: 1.0V p-p 75ohm

• Operating Voltage: 12V DC (Negative Ground)

• Operating Temperature: -20 Degrees C to +70 Degrees C
